LoimexLoimex · Electrical coilers
Loimex D30-2C — for high production with double coiling head 200mts/min
- Delivered across Southeast Asia
- Need help choosing? Call +65 6747 3336
About Loimex D30-2C — for high production with double coiling head 200mts/min
D30-2C — electrical coiler for high production with double coiling head 200mts/min.
Technical specification
| Measuring head | M40 ↗ |
|---|---|
| Mechanical counter type M410 | Yes |
| Ø exterior mm | 600 |
| Ø maximum core mm | 250 |
| Ø minimum core mm | 215 |
| width mm | 150 |
| Maximum weight kg. | 50 |
| Ø exterior mm | 600 |
| width mm | 350 |
| Maximum weight kg. | 200 |
| Speed ( R.P.M.) | 30-200 |
| Power kW (HP) | 1,1(1,5) |
| Torque Nm. | 221 |
| Voltage (V / Hz) | 230/50-60 ( opt 220III V ) |
| Fusing | 1x16 A |
Manufactured by Loimex. Supplied and serviced in Singapore and across ASEAN by Everwell Cables & Electrical (S.E.A.) Pte Ltd. Contact us for specification advice, lead time and pricing.
